Transplant Control Cable

Transplant Control Cable

Transplant Control Cable

Conductor: Cooper Conductor of Class 5/6 (Stranded)
Insulation: PVC
Insulation Color: Colors or Black with Number
Shield: Cooper Braid , Tineed Cooper Braid , or AL Foil
Jacket: transplant PVC
Temperature Range: -10℃ —- +70℃
Nominal Voltage: 300/500V , 450/750 V

1.Introduction of  Transplant Control Cable

Transplant Control Cable Widely used in industrial machinery, complete sets of equipment installation project, power station, heating and air conditioning installation, machine tools, conveyor systems, assembly lines, production lines,automation office equipment and other fields. Welcome to inquiry.



Properties

Grafted control cable with stranded tinned copper conductors, cross-linked polyethylene (XLPE) insulation and a fire resistant sheath of high quality. The multi-stranded tinned copper conductor provides excellent flexibility and conductivity, making it ideal for industrial control applications. XLPE insulation provides excellent insulation properties, reducing signal loss and interference. The fire jacket provides excellent fire protection and is ideal for use in high-risk environments.

Function

Designed to provide reliable and efficient performance for a range of industrial control applications. Its multi-strand tinned copper conductors provide excellent flexibility and conductivity, ideal for industrial control applications. XLPE insulation provides excellent insulation performance, reducing signal loss and interference. The safe Fire resistant cable provides excellent fire protection and is ideal for use in high risk environments.

Benefits

Offers a number of benefits that make it ideal for a variety of industrial control applications. First, its multi-strand tinned copper conductors offer excellent flexibility and conductivity, making it ideal for industrial control applications. Second, its XLPE insulation provides excellent insulation performance, reducing signal loss and interference. Third, its fire-resistant jacket provides excellent fire protection, making it ideal for use in high-risk environments. Finally, it is available in a variety of sizes and lengths, making it suitable for a range of industrial control setups.

Applications

It is ideally suited for use in manufacturing, automation and robotics, including machine control and process control. Its high performance design also makes it suitable for industries that require high precision and reliability, such as aerospace and defense.

Installation

It is recommended that the cable be installed according to the manufacturer’s instructions to ensure proper installation and to prevent damage to the cable. Cables can be cut to the required length using wire cutters or cable shears, and can be terminated using a range of connectors, including crimp connectors and solder connectors.

Maintenance

Graft control cable is a durable product that requires minimal maintenance. However, it is recommended that the cable be inspected regularly to ensure it is working properly. Any damaged cables should be replaced immediately to prevent further damage or injury. It is also recommended that the cable be cleaned periodically to remove any dirt or debris that may have accumulated on the cable.

2.Parameter (Specification) of  Transplant Control Cable

Description

Transplant Control Cable

Conductor:

Stranded Copper Conductor of Class 5/6 (Flexible)

Insulation:

PVC Compound

 Insulation Color

can be customized

Wrap

PET tape covered.

Shield:

(Tinned) copper shielding ,braid coverage of 85%

Sheath

PVC

Sheath Color

Transplant

Rated Temperature

 70℃

Rated voltage:

300/500V ,  450/750 V

Test Voltage:

2500 V

Minimal Bending Radius:

  8D



Technical Data



Cores x section mm2

O.D.

mm

Cu weight

Kg/100m

Cable weight

Kg/100m

3 G 0,5

7,3

45.5

83

4 G 0,5

7,9

55.0

99

5 G 0,5

8,4

66.0

112

7 G 0,5

8,9

80.5

132

12 G 0,5

11,3

138.5

202

18 G 0,5

13,3

156.4

289

25 G 0,5

15,2

250.0

378

30 G 0,5

16,1

297.0

429

40 G 0,5

18,2

343.0

542

2 G 0,75

7,4

46.0

86

3 G 0,75

7,9

57.9

100



3. What is a custom control cable?

Custom control cables are cables that are designed and manufactured to meet specific requirements for a particular application. These cables are typically used in industries such as aerospace, automotive, marine, and industrial machinery. Custom control cables are used to transmit mechanical force, motion, and energy from one point to another in a controlled manner.

4. How to make custom control cables?

Custom control cables can be made from a variety of materials, including stainless steel, galvanized steel, nylon-coated steel, and aluminum. They can also be designed to have different sizes, lengths, and configurations to meet the specific needs of the application.

The word “custom” shows that the production of custom control cables is more complicated and precise than ordinary control cables. Typically, the process of designing and manufacturing custom control cables involves working with a cable manufacturer or supplier who can provide expert guidance and support throughout the process. This includes assistance with the design and engineering of the cable, material selection, and custom manufacturing to ensure the cable meets the specific requirements of the application

5.What do we ask of ourselves?

Control cables due to the attribute of their application,and there are many demands on them:

1)Precisely in Action

2)Suited for the environment

3)Easy to mount/dismount in complex restricted space

4)Flexible to be adjusted/recalibrated in its operational lifetime.

6. What will we encounter?

Although with the rapid development of the national economy, the degree of automation is getting higher and higher, and the use of control cables is becoming more and more extensive. Custom control cables will also encounter the same failure as ordinary control cables, and there are many reasons for the failure.

(1) Limited by the construction conditions on site, the custom control cables are subjected to strong external forces when they are passed through the pipes and laid along the bridge, and the insulation sheath is damaged or twisted seriously, burying hidden dangers for normal operation.

(2) Very few custom control cables are too long, the joints are not obvious, no joints were found during construction, and the joints were not specially treated and used directly. After running for a period of time, they became hot and malfunctioned.

(3) The length of the custom control cable is not enough during construction, and the construction unit joints the cables. The process of jointing is simple and the insulation strength is low, which lays hidden danger for normal operation.

(4) Due to the limitation of the working environment, the cable works in a place with high temperature, high humidity, greasy or high vibration for a long time, and the insulation sheath is damaged, which reduces the insulation capacity of the cable.

(5) During the re-construction, due to the unknown direction of the cable, the insulation sheath was damaged by external force.

7.Feature of the Transplant Control Cable

1)Conductor: Flexible stranded bare copper wire. Multi-conductor.
2) Insulation: PVC insulation.

3)Jacket: transplant PVC





8.Detail of the Transplant Control Cable

1) Conditionally resistant to water,oils,acids,alkali.
2) Standard sizes and custom color available upon request
3) Outstanding resistance to abrasion, deformation.
4) Brand: Anyte





9. Packaging & Delivery

1) Packaging Details:

It is determined by the quantity and requirements you purchase. Can be negotiated.

2) Port: SHANGHAI, NINGBO

Delivery: By Sea, By Air, By express.



10.FAQ

What is your lead time for bulk goods?

A: Honestly, it depends on order quantity and cable material. Normal lead time is around 2-3weeks.

Q: How do you guarantee the quality?

A: We are an UL/TUV/CSA/SAA/ISO9000.1 certificated company. All our materials are RoHS 2.0. When production,For each step inspector is on routing inspection, and 100% test before delivery.
