Multicore Solid Cable

Multicore Solid Cable

Multicore Solid Cable

Conductor: Cooper Conductor of Class 1/2 (Solid)
Insulation: PVC
Insulation Color: Colors or Black with Number
Jacket: PVC
Temperature Range:-10 —- +70℃
Nominal Voltage: 300/500V , 450/750 V , 0.6/1KV

1.Introduction of Multi Core Solid Cable

Multi Core Solid Cable is suitable for building and machine.The insulation and outer sheath provided here is PVC. Bare copper, solid wire conductor. Can add resistant to acids, heat, cold, abrasion resistance, oil resistance, environmental protection and other features. Welcome to inquiry.



2.Parameter (Specification) of Multi Core Solid Cable



Description

Multi Core Solid Cable

Conductor:

Solid Copper Conductor of Class 1/2 (Solid)

Insulation:

PVC Compound

Insulation Color

Red, Blue, Yellow/Green or as requested

Sheath

PVC Compound

Sheath Color

Black, Grey or as requested

Rated Temperature

 70℃

Rated voltage:

300/500V ,  450/750 V , 0.6/1KV

Test Voltage:

2500 V

Minimal Bending Radius:

 12D

Standard

IEC 60502



Technical Data

Conductor

cores

insulation

jacket

20℃ Max. Conductor resistant

70℃

Min. insulation resistant

Test Voltage

Section area

No./mm

O.D.



thickness

O.D.

thickness

O.D.









No./mm

mm

No

mm

mm

mm

mm

mm

Ω/Km

MΩ.Km

V

1.5

1/1.38

1.38

2

0.7

2.78

1.2

7.6

10

12.1

0.011











2500

7/0.524

1.57

0.7

2.97

1.2

7.8

10.5

12.1

0.01

2.5

1/1.78

1.78

0.8

3.38

1.2

8.6

11.5

7.41

0.01

7/0.674

2.02

0.8

3.62

1.2

9

12

7.41

0.009

4

1/2.24

2.24

0.8

3.84

1.2

9.6

12.5

4.61

0.0085

7/0.85

2.55

0.8

4.15

1.2

10

13

4.61

0.0077

6

1/2.76

2.76

0.8

4.36

1.2

10.5

13.5

3.08

0.007

7/1.04

3.12

0.8

4.72

1.2

11

14

3.08

0.0065

10

7/3.56

3.56

0.8

5.56

1.4

13

16.5

1.83

0.007

7/1.35

4.05

1

6.05

1.4

13.5

17.5

1.83

0.0065

16

7/1.70

5.1

1

7

1.4

15.5

20

1.15

0.0052

25

7/2.13

6.39

1.2

8.79

1.4

20.5

26

0.727

0.005



3.Feature of the Multi Core Solid Cable



1) Easy stripping and cutting
2) RoHS2.0 & Reach compliant
3) Can add resistant to acids, heat, cold, abrasion resistance, oil resistance, environmental protection and other features



4.Detail of the Multi Core Solid Cable



1) Conditionally resistant to water,oils,acids,alkali.
2) Standard sizes and custom color available upon request (black, red, yellow,orange,green,white…).
3) Outstanding resistance to abrasion, deformation.
4) Brand: Anyte





5 Packaging & Delivery



1) Packaging Details:

It is determined by the quantity and requirements you purchase.  Can be negotiated.



2) Port: SHANGHAI, NINGBO



Delivery: By Sea, By Air, By express.



6 FAQ:

What is your lead time for bulk goods?

A: Honestly, it depends on order quantity and cable material. Normal lead time is around 2-3weeks.



Q: How do you guarantee the quality?

A: We are an UL/TUV/CSA/SAA/ISO9000.1 certificated company. All our materials are RoHS 2.0. When production,For each step inspector is on routing inspection, and 100% test before delivery.
